Panizzolo Mega 7 Series
Panizzolo Mega 7 Series 725/735
Technical Data
| Model: | MEGA 725 | MEGA 735 |
| Production (up to): | 25ton/h* | 35ton/h* |
| Motor power: | 355kW | 450kW |
| Total weight: | 67500kg | 84000kg |
| Hammers: | n.24 - 52kg/each | n.32 - 52 kg/each |
| Rotor weight: | 5200kg | 8800kg |
| Cradle weight: | 5400kg | 7700kg |
| Inlet opening appr dim: | 1000 x 850mm | 1400 x 1000mm |
| Machine appr dim: | 18200 x 3750x 7750mm | 20500 x 4200 x 8650mm |
| Magnetic drum module appr. dim.: | 5000 x 3000 x 3300mm | 5000 x 3000mm |
*depending on grid and materials type
Mega 725
Mega 735
Video of this machine in action
